Ubiquiti WAVE-PRO 60GHz+5GHz max. 5,4Gbps ( až 15km)
High-capacity 60 GHz radio that supports long-distance PtP (bridge) and PtMP links.Max. link range: — PtP: Up to 15 km— PtMP: Up to 8 km (Wave AP), up to 6 km (Wave AP Micro)Max. total throughput: 5.4…
Specifikacia Ubiquiti WAVE-PRO 60GHz+5GHz max. 5,4Gbps ( až 15km)
High-capacity 60 GHz radio that supports long-distance PtP (bridge) and PtMP links.Max. link range: — PtP: Up to 15 km— PtMP: Up to 8 km (Wave AP), up to 6 km (Wave AP Micro)Max. total throughput: 5.4 Gbps (2.7 Gbps duplex)5 GHz weatherproof backup radio (Max. throughput: 800 Mbps)(2) 2.5 GbE and (1) 10G SFP+ portsErgonomic transportation handlePrecision alignment mountIntegrated GPS & BluetoothMechanical Dimensions O424.4 x 166.2 mm (O16.7 x 6.5") Weight Without mount: 2.8 kg (6.2 lb) With mount: 4 kg (8.8 lb) Enclosure material Aluminum alloy, UV stabilized plastic Mount material Stainless steel Pole mount diameter 25 to 76.2 mm (1 to 3") on pipe outer diameter Wind loading 369 N at 200 km/h (83 lbf at 125 mph) Weatherproofing IPX6 Hardware Processor Quad-core ARM® Cortex®-A53 at 1.4 GHz Memory DDR3L 512 MB Networking interface (2) 2.5 GbE RJ45 ports (1) 10G SFP+ port Max. power consumption 26W Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only Power supply 48V DC, 0.65A, 2.5 GbE PoE adapter (Included) Supported voltage range 44–54V DC 22–27V DC GPS Yes Button Factory reset LEDs Power, (2) Ethernet, SFP+ , GPS, link Ambient operating temperature -40 to 60° C (-40 to 140° F) Ambient operating humidity 5 to 95% noncondensing Certifications FCC, IC, CE Software Operating mode PtP, PtMP station Ubiquiti specific features Integrated 60 GHz radio, discovery protocol, Wave technology Services UISP, ping watchdog, NTP client, SNMP Tools Antenna alignment, discovery utility, ping, trace route, speed test, cable test*, site survey*, traffic shaping** *FW version 3.3.0 and later. **FW version 3.4.0 and later. Network Bridge/Router* mode *Router is available in PtMP station mode only. Application requirements UISP: Version 2.3.0 and later System Total throughput 5.4 Gbps (2.7 Gbps duplex) Max. range PtP: Up to 15 km PtMP: Up to 8 km (Wave AP), up to 6 km (Wave AP Micro) Encryption WPA2-PSK (AES) RF Operating frequency* 57 to 71 GHz *Depends on regulatory region. Channel bandwidth 2160, 1080, 540* MHz *FW version 3.3.0 and later. Operating channels* 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz *Depends on regulatory region. Modulation 16QAM, QPSK Antenna gain 46 dBi Polarization Vertically linear Beamwidth Azimuth: 3 dB 1.3° Elevation: 3 dB 1.3° Back-Up RF WiFi Standard 802.11ax (WiFi 6) Operating frequency* US/CA Worldwide U-NII-1 5150 - 5250 MHz U-NII-2A 5250 - 5350 MHz U-NII-2C 5470 - 5725 MHz U-NII-3 5725 - 5850 MHz5150 - 5875 MHz *Depends on regulatory region. Channel bandwidth 20, 40, 80 MHz Max. conducted TX power 27 dBm Modulation BPSK (1⁄2), QPSK (1⁄2), QPSK (3⁄4), 16QAM (1⁄2), 16QAM (3⁄4), 64QAM (2⁄3), 64QAM (3⁄4), 64QAM (5⁄6), 256QAM (3⁄4), 256QAM (5⁄6), 1024QAM (3⁄4), 1024QAM (5⁄6) Antenna gain 22 dBi Polarization Dual-linear Beamwidth Azimuth: 3 dB 8° Elevation: 3 dB 8° Cross-pol isolation 20 dB LEDs Power Flashing white: bootup in progress White: not connected to UISP application Blue: connected to UISP application Flashing blue: locate in progress Blue/white: firmware upgrade in progress Ethernet (2) Flashing blue: Ethernet traffic detected SFP+ (1) Flashing blue: SFP+ traffic detected Links White: 5 GHz link Blue: 60 GHz link GPS Blue: receiving at least (4) GPS satellite signal
