Ubiquiti WAVE-NANO 60GHz+5GHz max. 2Gbps ( až 5km)

Specifikacia Ubiquiti WAVE-NANO 60GHz+5GHz max. 2Gbps ( až 5km)

60 GHz PtMP station powered by Wave Technology.Max. link range: — Wave AP: 5 km— Wave AP Micro: 4 kmMax. total throughput: 2 Gbps (1 Gbps duplex)5 GHz weatherproof backup radio (Max. throughput: 800 Mbps)(1) GbE RJ45 portIntegrated GPS & BluetoothMechanical Dimensions O256.5 x 113.5 mm (O10.1 x 4.5") Weight Without mount: 932 g (2.1 lb) With mount: 1.2 kg (2.6 lb) Enclosure material Aluminum alloy, UV stabilized plastic Mount material Aluminum alloy, UV stabilized plastic Pole mount diameter 25 to 63.5 mm (1 to 2.5") on pipe outer diameter Wind loading 127 N at 200 km/h (28.6 lbf at 125 mph) Weatherproofing IPX6 Hardware Processor Dual-core ARM® Cortex®-A53 at 1 GHz Memory DDR3L 512 MB Networking interface (1) GbE RJ45 port Max. power consumption 20W Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only Power supply 48V DC, 0.65A gigabit PoE adapter (Included) Can be powered by a UISP Router or UISP Switch Supported voltage range 44–54V DC 22–27V DC GPS Yes Button Factory reset LEDs Power, Ethernet, GPS, link Ambient operating temperature -40 to 60° C (-40 to 140° F) Ambient operating humidity 5 to 95% noncondensing Certifications FCC, IC, CE Software Operating mode PtMP station, PtP* *FW version 3.2.0 and later. Ubiquiti specific features Wave AI, discovery protocol Services UISP, ping watchdog, NTP client, SNMP Tools Antenna alignment, discovery utility, ping, trace route, speed test, cable test*, site survey*, traffic shaping** *FW version 3.3.0 and later. **FW version 3.4.0 and later. Network Bridge/Router* mode *Router is available in PtMP station mode only. Application requirements UISP: Version 1.4.5 and later System Total throughput 2 Gbps (1 Gbps duplex) Max. range 5+ km Encryption WPA2-PSK (AES) RF Operating frequency* 57–71 GHz *Depends on regulatory region. Channel bandwidth 2160, 1080, 540* MHz *FW version 3.3.0 and later. Operating channels* 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz *Depends on regulatory region. Modulation 16QAM, QPSK Antenna gain 41 dBi Polarization Vertically linear Beamwidth Azimuth: 3 dB 1.4° Elevation: 3 dB 1.4° Back-Up RF WiFi standard 802.11ax (WiFi 6) Operating frequency* US/CA Worldwide U-NII-1 5150 - 5250 MHz U-NII-2A 5250 - 5350 MHz U-NII-2C 5470 - 5725 MHz U-NII-3 5725 - 5850 MHz5150 - 5875 MHz *Depends on regulatory region. Channel bandwidth 20, 40, 80 MHz Modulation BPSK (1⁄2), QPSK (1⁄2), QPSK (3⁄4), 16QAM (1⁄2), 16QAM (3⁄4), 64QAM (2⁄3), 64QAM (3⁄4), 64QAM (5⁄6), 256QAM (3⁄4), 256QAM (5⁄6), 1024QAM (3⁄4), 1024QAM (5⁄6) Antenna gain 19 dBi Polarization Dual-linear Beamwidth Azimuth: 3 dB 14° Elevation: 3 dB 14° Cross-pol isolation 20 dB LEDs Power Flashing white: bootup in progress White: not connected to UISP application Blue: connected to UISP application Flashing blue: locate in progress Blue/white: firmware upgrade in progress Ethernet Flashing blue: Ethernet traffic detected GPS Blue: receiving at least (4) GPS satellite signal Links White: 5 GHz link Blue: 60 GHz link
