Ubiquiti WAVE-AP-MICRO 60GHz+5GHz max. 5Gbps ( až 6km)

Specifikacia Ubiquiti WAVE-AP-MICRO 60GHz+5GHz max. 5Gbps ( až 6km)

Wide-coverage 60 GHz PtMP access point powered by Wave Technology.Max. total throughput: 5 Gbps (2.5 Gbps duplex)90° sector coverage5 GHz weatherproof backup radio (Max. throughput: 800 Mbps)(1) 2.5 GbE WAN port31* client capacity: — Wave Pro (6 km link range)— Wave Long-Range (6 km link range)— Wave Nano (4 km link range)— Wave Pico (0.9 km link range)Integrated GPS & Bluetooth Mechanical Dimensions 284 x 156 x 76 mm (11.2 x 6.1 x 3") Weight 1.3 kg (2.9 lb) Enclosure material Aluminum alloy, UV stabilized polycarbonate Mount material Stainless steel, UV stabilized polycarbonate Pole mount diameter 35 to 60 mm (1.4 to 2.4") on pipe outer diameter Wind loading 87 N at 200 km/h (20 lbf at 125 mph) Weatherproofing IPX6 Hardware Processor Quad-core ARM® Cortex®-A53 at 1.4 GHz Memory DDR3L 512 MB Networking interface (1) 1/2.5 GbE RJ45 port Max. power consumption 24W Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only Power supply 48V DC, 0.65A, 2.5 GbE PoE adapter (Included) Supported voltage range 44–54V DC 22–27V DC GPS Yes Button Factory reset LEDs Power, Ethernet, GPS, Link Ambient operating temperature -40 to 60° C (-40 to 140° F) Ambient operating humidity 5 to 95% noncondensing Certifications FCC, IC, CE Software Operating mode PtMP access point Ubiquiti specific features Wave AI, discovery protocol Services UISP, ping watchdog, NTP client, SNMP Tools Antenna alignment, discovery utility, ping, trace route, speed test, cable test*, site survey* *FW version 3.3.0 and later. Network Bridge mode Application requirements UISP web: Version 2.2.11 and later UISP mobile iOS™: Version 2.25.1 and later UISP mobile Android™: Version 2.27.5 and later System Total throughput 5 Gbps (2.5 Gbps duplex) Supported clients count 31* *FW version 3.4.0 and later. Max. range Connecting to a Wave Pro: up to 6 km Connecting to a Wave Long-Range: up to 6 km Connecting to a Wave Nano: up to 4 km Connecting to a Wave Pico: up to 0.9 km Encryption WPA2-PSK (AES) RF Operating frequency* 57–71 GHz *Depends on regulatory region. Channel bandwidth 2160, 1080, 540* MHz *FW version 3.3.0 and later. Operating channels* 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz *Depends on regulatory region. Modulation 16QAM, QPSK Antenna gain 20 dBi Polarization Vertically linear Beamwidth Azimuth: 3 dB 90° Elevation: 3 dB 7° Electrical downtilt 0° Back-Up RF WiFi standard 802.11ax (WiFi 6) Operating frequency* US/CA Worldwide U-NII-1 5150 - 5250 MHz U-NII-2A 5250 - 5350 MHz U-NII-2C 5470 - 5725 MHz U-NII-3 5725 - 5850 MHz5150 - 5875 MHz *Depends on regulatory region. Channel bandwidth 20, 40, 80 MHz Modulation BPSK (1⁄2), QPSK (1⁄2), QPSK (3⁄4), 16QAM (1⁄2), 16QAM (3⁄4), 64QAM (2⁄3), 64QAM (3⁄4), 64QAM (5⁄6), 256QAM (3⁄4), 256QAM (5⁄6), 1024QAM (3⁄4), 1024QAM (5⁄6) Antenna gain 13.5 dBi Polarization Dual-linear Beamwidth Azimuth: 6 dB 90° Elevation: 6 dB 25° Cross-pol isolation 10 dB Electric downtilt 0° LEDs Power Flashing white: bootup in progress White: not connected to UISP application Blue: connected to UISP application Flashing blue: locate in progress Blue/white: firmware upgrade in progress Ethernet Flashing blue: Ethernet traffic detected GPS Blue: receiving at least(4) GPS satellite signal Link Blue: 60 GHz link White: 5 GHz link
