Ubiquiti WAVE-PICO 60GHz+5GHz max. 2Gbps ( až 1,3km)

Specifikacia Ubiquiti WAVE-PICO 60GHz+5GHz max. 2Gbps ( až 1,3km)

Lightweight, compact 60 GHz PtMP station powered by Wave Technology.Max. link range: — Wave AP: 1.3 km— Wave AP Micro: 0.9 kmMax. total throughput: 2 Gbps (1 Gbps duplex)5 GHz weatherproof backup radio (Max. throughput: 800 Mbps)(1) GbE RJ45 portIntegrated Bluetooth Mechanical Dimensions O152.1 x 55.8 mm (O6 x 2.2") Weight Without mount: 347 g (12.2 oz) With mount: 409 g (14.4 oz) Enclosure material UV stabilized polycarbonate Mount material UV stabilized polycarbonate Pole mount diameter 20 to 53.1 mm (0.8 to 2.1") on pipe outer diameter Wind loading 31.3 N at 200 km/h (7 lbf at 125 mph) Weatherproofing IPX6 Hardware Processor Dual-core ARM® Cortex®-A53 at 1 GHz Memory DDR3L 512 MB Networking interface (1) GbE RJ45 port Max. power consumption 10W Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8 -) Passive PoE 2-pairs (4, 5+; 7, 8 -), for 44–54V DC only Power supply 48V DC, 0.5A gigabit PoE adapter (Included) Can be powered by a UISP Router or UISP Switch Supported voltage range 44–54V DC 22–27V DC GPS No Button Factory reset LEDs Power, Ethernet, link Ambient operating temperature -40 to 60° C (-40 to 140° F) Ambient operating humidity 5 to 95% noncondensing Certifications FCC, IC, CE Software Operating mode PtMP station, PtP Ubiquiti specific features Wave AI, discovery protocol Services UISP, ping watchdog, NTP client, SNMP Tools Antenna alignment, discovery utility, ping, trace route, speed test, cable test*, site survey*, traffic shaping** *FW version 3.3.0 and later. **FW version 3.4.0 and later. Network Bridge/Router* mode *Router is available in PtMP station mode only. Application requirements UISP web: Version 2.4.61 and later UISP mobile iOS™: Version 2.32.0 and later UISP mobile Android™: Version 2.31.9 and later System Total throughput 2 Gbps (1 Gbps duplex) Max. range Up to 1.3 km (Wave AP) Up to 0.9 km (Wave AP Micro) Encryption WPA2-PSK (AES) RF Operating frequency* 57–71 GHz *Depends on regulatory region. Channel bandwidth 2160, 1080, 540* MHz *FW version 3.3.0 and later. Operating channels* 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz *Depends on regulatory region. Modulation 16QAM, QPSK Antenna gain 27.7 dBi Polarization Vertically linear Beamwidth Azimuth: 3 dB 6° Elevation: 3 dB 6° Back-Up RF WiFi standard 802.11ax (WiFi 6) Operating frequency* US/CAWorldwide U-NII-1 5150 - 5250 MHz U-NII-2A 5250 - 5350 MHz U-NII-2C 5470 - 5725 MHz U-NII-3 5725 - 5850 MHz5180 - 5875 MHz *Depends on regulatory region. Channel bandwidth 20, 40, 80 MHz Modulation BPSK (1⁄2), QPSK (1⁄2), QPSK (3⁄4), 16QAM (1⁄2), 16QAM (3⁄4), 64QAM (2⁄3), 64QAM (3⁄4), 64QAM (5⁄6), 256QAM (3⁄4), 256QAM (5⁄6), 1024QAM (3⁄4), 1024QAM (5⁄6) Antenna gain 9 dBi Polarization Dual-linear Beamwidth Azimuth: 3 dB 50° Elevation: 3 dB 50° Cross-pol isolation 15 dB LEDs Power Flashing white: bootup in progress White: not connected to UISP application Blue: connected to UISP application Flashing blue: locate in progress Blue/white: firmware upgrade in progress Ethernet Flashing blue: Ethernet traffic detected Links White: 5 GHz link Blue: 60 GHz link
