Ubiquiti UniFi Protect Network Video Recorder Instant…
Compact UniFi Protect NVR with 3.5" HDD support, featuring an integrated 6-port PoE switch, integrated HDMI View Port, and a capacity for (6) 4K camera or (15) Full HD cameras. Technical…
Specifikacia Ubiquiti UniFi Protect Network Video Recorder Instant…
Compact UniFi Protect NVR with 3.5" HDD support, featuring an integrated 6-port PoE switch, integrated HDMI View Port, and a capacity for (6) 4K camera or (15) Full HD cameras. Technical Specifications Overview Dimensions 220 x 220 x 47 mm UniFi Application Suite Protect Yes Access Yes Managed Cameras (15) HD (8) 2K (6) 4K Storage Capacity (1) 3.5" drive bay Data Protection Yes Vantage Point Yes Networking Interface (1) GbE RJ45 uplink port (6) GbE PoE RJ45 downlink ports (1) HDMI port (Viewport) Form Factor Compact Desktop Mounting Wall, Din rail mount (Included) Hardware Hard Drive Capacity (1) 3.5" HDD support Max. Power Budget for Drives 11W Max. Power Consumption 9W Power Method Universal AC input, 100-240VAC, 1.5A Max, 50/60 Hz Power Supply AC/DC, Internal, 60W PoE Budget 40W Max. PoE Wattage per Port by PSE PoE 15.4W Voltage Range PoE Mode 44–57V Processor Quad-core ARM Cortex-A55 at 1.7 GHz Memory 4 GB Management Ethernet / Bluetooth Display 1.14" screen Weight 1.04 kg (2.3 lb) Enclosure Material Polycarbonate Mount Material Polycarbonate LEDs Ethernet Yes PoE Yes Ambient Operating Temperature 0 to 40° C (32 to 104° F) Ambient Operating Humidity 5 to 95% noncondensing NDAA Compliant Yes Certifications FCC, IC, CE, Electrical Safety, UL
