HiLook VI-K46P - Interkom KIT YhlVIK46P

Door station/System parameters Operation system Linux Processor Embeded high performance processor RAM 256 MB ROM 32 MB Door station/Video parameters Supplement light IR light, up to 3 m Resolution Main stream: 1920 × 1080p Sub stream: 704 × 576p Lens 2MP HD camera Wide dynamic range (WDR) 120 dB Field of view Horizontal: 131°, Vertical: 78° Video Compression Standard H.264 Door station/Audio parameters Audio input 1 built-in omnidirectional microphone Audio output 1 built-in loudspeaker Audio quality Noise suppression and echo cancellation Volume adjustment Adjustable Audio compression standard G.711 U Audio compression Rate 64 Kbps Door station/Capacity parameters User capacity 2000 Linked indoor station capacity 16 Card capacity 10000 Door station/Network parameters Network protocol TCP/IP, RSTP Door station/Device interfaces Network interface 1 RJ-45, 10/100 Mbps self-adaptive RS-485 1 Alarm input 4 Lock control 1 relay, Max. 4 W Power supply IEEE802.3af, Standard PoE,12 VDC Working temperature -10 °C to 50 °C (14 °F to 122 °F) Working humidity 10% to 95% (no-condensing) Dimension (L x W x H) 200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6") Dimension (W × H × D) 120 mm × 120 mm × 21 mm (4.7" × 4.7" × 0.83") Installation Wall mounting, table mounting Application environment Indoor Protective level / With package: 336.6 g Without package: 197.8 g Language English, French, Portuguese, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Turkish, Vietnamese, Arabic, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian Danish, Slovenian, Slovak, Swedish, Finnish, Traditional Chinese, Mongolian, Hebrew, Kazakh, Uzbek 30 VDC 2 A Exit button 1 Door contact input 1 TAMPER 1 Door station/General Button 1 physical button(s) Power consumption < 10 W Working temperature -40 °C to 55 °C(-40 °F to 131 °F) Working humidity 10% to 95% (no-condensing) Dimension 138 mm × 65 mm × 27 mm (5.4" × 2.6" × 1.1") Installation Surface mounting Protection level IP65 Indicator 2 Application environment Outdoor Power supply IEEE802.3af, standard PoE 12 VDC Net weight: 0.190 kg; Gross weight: 0.414 kg Indoor station/System parameters Operation system Embedded Linux operation system RAM 128 MB ROM 16 MB Processor Embedded processor Indoor station/Display parameters Display resolution 480 × 272 Operation method Capacitive touch screen with 9 touch buttons Screen size 4.3-inch colorful TFT screen Type Colorful TFT screen Indoor station/Video parameter Video compression standard / Resolution / Lens / Wide dynamic range (WDR) / FOV / Indoor station/Audio parameters Audio input Built-in omnidirectional microphone Audio output Built-in loudspeaker Audio quality Noise suppression and echo cancellation Audio compression standard G.711 U, G.711 A Audio compression bitrate 64 Kps Volume adjustment Adjustable Indoor station/Capacity parameters Notice capacity 200 Linked indoor extensions capacity 16 Indoor station/Network parameters Network protocol TCP/IP, SIP, RTSP Wi-Fi Wi-Fi 802.11 b/g/n, 2.4 GHz Indoor station/Device interfaces Network interface 1 RJ-45 10/100 Mbps self-adaptive Alarm input 4 Indoor station/General Button 9 physical button Power consumption ?
